ACCESS POINT TP-LINK EAP610-OUT AC1200 MU-MIMO POE
| CARACTERÍSTICAS DE HARDWARE | |
|---|---|
| Interface | 1× Gigabit Ethernet (RJ-45) Port (Support 802.3at PoE and Passive PoE) |
| Botón | Reset |
| Fuente de alimentación | • 802.3at PoE • 48V/0.5A Passive PoE (PoE Adapter Included) |
| Consumo de Poder | • 12.5 W for PoE • 10 W for DC |
| Dimensiones (An x Pr x Al) | • 280.4×106.5×56.8 mm (without antenna & mounting kit) |
| Antena | • 2.4 GHz: 2× 4 dBi • 5 GHz: 2× 5 dBi |
| Recinto resistente a la intemperie | IP67 |
| Montaje | Pole/Wall Mounting (Kits included) |
| CARACTERÍSTICAS INALÁMBRICAS | |
|---|---|
| Wireless Client Capacity | 250+△ |
| Estándares inalámbricos | IEEE 802.11ax/ac/n/g/b/a |
| Frecuencia | 2.4 GHz, 5 GHz |
| Tasa de señal | • 802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80) • 802.11ac: 5G:6.5 Mbps to 867 Mbps(MCS0-MCS9,NSS = 1 to 2 VHT20/40/80) 2.4G:78 Mbps to 300 Mbps (MCS8-MCS9 VHT20/40, NSS=1 to 3) • 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40) • 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps • 802.11b: 1, 2, 5.5, 11 Mbps • 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Potencia de Transmision | • CE: <15 dBm (2.4 GHz, EIRP), <22 dBm(5 GHz, EIRP) • FCC: <22 dBm (2.4 GHz), <22 dBm(5 GHz) |
| Funciones inalámbricas | • 1024-QAM • 4× Longer OFDM Symbol • OFDMA • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS (WMM) • MU-MIMO • Omada Mesh • Seamless Roaming • Band Steering • Load Balance • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client |
| Seguridad inalámbrica | • Captive Portal Authentication • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support • WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| ADMINISTRACIÓN | |
|---|---|
| Aplicación Omada | Yes |
| Gestión centralizada | • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller |
| Acceso a la nube | Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) |
| Alertas de correo electrónico | Yes |
| Gestión de control de acceso MAC | Yes |
| SNMP | v1, v2c |
| Registro del sistema Local / Remote Syslog | Yes |
| SSH | Yes |
| Gestión basada en web | Yes |
| Gestión L3 | Yes |
| Gestión de múltiples sitios | Yes |
| VLAN de administración | Yes |
| OTROS | |
|---|---|
| Certificación | CE, FCC, RoHS |
| contenidos del paquete | • Access Point EAP610-Outdoor • Passive PoE Adapter • Power Cord • Mounting Kits • Waterproof Kits • Waterproof Antenna • Installation Guide |
| Requisitos del sistema | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Ambiente | • Operating Temperature: -30–70 ℃ (-22–158 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing |
